Thrust spherical roller bearing 29230 series

Thrust spherical roller bearing 29230 series

Thrust spherical roller bearing 29230 series

Product name：Spherical roller bearing
cage: E EM M E-MB
clearance：C0 C3 C4
Material:Chrome Steel

INQUIRY

Product Details

Product Tags

Spherical roller bearingcage.jpg Spherical roller bearing1.jpg

Designation	old model	Principal Dimension			Basic Load Ratings（KN）		Speed ratings(r/min)		Weight
Designation	old model	d	D	B	Dynamic	Static	Grease	Oil	kg
29230	9039230	150	215	39	425	1720	3150	1540	6.3
29234	9039232	170	240	42	470	1940	2800	1390	7
29236	9039234	180	250	42	485	2070	2650	1350	7.5
29238	9039236	190	270	48	520	2500	2440	1300	8
29240	9039238	200	280	48	536	2270	1600	1280	8.9
29244	9039240	220	300	48	542	2490	1550	1160	10
29248	9039244	240	340	60	822	3680	1250	1060	16.7
29252	9039248	260	360	60	838	3720	1200	970	18.5
29256	9039252	280	380	60	862	4020	1150	900	19.5
29260	9039256	300	420	73	1070	4890	950	830	30.5
29264	9039260	320	440	73	1110	2170	900	780	32.9
29268	9039264	340	460	73	1150	5300	900	740	33.6
29272	9039268	360	500	85	1460	6450	750	690	51.8
29276	9039272	380	520	85	1580	7430	700	660	52.8
29280	9039276	400	540	85	1610	7850	700	620	55.3
29284	9039280	420	580	95	1990	9620	600	580	75.4
29288	9039284	440	600	95	2060	9830	600	560	77.9
29292	9039288	460	620	95	2150	10200	550	540	81
29296	9039292	480	650	103	2350	11600	500	520	89

Spherical roller bearing5.jpg
