Product name：High temperature bearing 6000 series
clearance：C0 C3 C4
Material:High temperature Chrome Steel

INQUIRY

Product Details

Product Tags

deep groove ball bearing3.jpg

High temperature bearing.jpg

Designation	Principal Dimension			Basic Load Ratings（KN）		Speed ratings(r/min)		Weight (kg)
Designation	d	D	B	Cr	Cor	Grease	Oil	Weight (kg)
6010	50	80	16	2220	1700	8500	10000	0.261
6011	55	90	18	2880	2170	7500	9000	0.381
6012	60	95	18	3000	2370	7100	8500	0.412
6013	65	100	18	3100	2570	6700	8000	0.439
6014	70	110	20	3900	3150	6000	7100	0.608
6015	75	115	20	4050	3400	5600	6700	0.649
6016	80	125	22	4850	4050	5300	6300	0.872
6017	85	130	22	5050	4400	5000	6000	0.918
6018	90	140	24	5950	5050	4800	5600	1.19
6019	95	145	24	6150	5500	4500	5300	1.23
6020	100	150	24	6150	5550	4300	5300	1.29
6021	105	160	26	7400	6700	4000	4800	1.58
6022	110	170	28	8650	7450	3800	4500	1.94
6024	120	180	28	9000	8150	3600	4300	2.08
6026	130	200	33	10800	10300	3000	3600	3.26
6028	140	210	33	11200	11100	2800	3400	3.48
6030	150	225	35	12800	12800	2600	3000	4.24
6032	160	240	38	13900	13800	2400	2800	5.15
6034	170	260	42	16400	16400	2200	2600	6.89
6036	180	280	46	18400	18800	2000	2400	8.88
6038	190	290	46	19200	20500	2000	2400	9.39
6040	200	310	51	21100	23000	1900	2200	12
6044	220	340	56	24000	27600	1700	2000	18.6
6048	240	360	56	24900	30000	1500	1900	19.9
6052	260	400	65	29700	38500	1400	1800	29.4
6056	280	420	65	31000	41500	1300	1750	31.2
6060	300	460	74	36500	51000	1200	1600	44.2
6064	320	480	74	40000	58000	1100	1500	46.5
6068	340	520	82	45000	67500	1000	1350	62.3
6072	360	540	82	47000	73500	900	1300	65.3
6076	380	560	82	46500	74000	800	1200	68
6080	400	600	90	52000	84000	700	1100	88.4
6084	420	620	90	54000	91000	600	1000	92.2
6092	460	680	100	62000	110000	500	900	123
6096	480	700	100	61500	111000	400	800	127

High temperature bearing1.jpg
